• Power Ratings:
Bridged Power (Amps Driving Single Load Together):
800 W RMS @ 8 ohms
1200 W RMS @ 4ohms
2000 W burst @ 4 ohms
Dual Mono Power (Amps Driving Load Separately):
300 W RMS @ 8 ohms per channel
400 W RMS @ 4 ohms per channel
600 W RMS @ 2 ohms per channel
700 W burst @ 4 ohms per channel
1000 W burst @ 2 ohms per channel
RMS = Continuous Power
• Preamp: Solid State
• Power Amp: Class H, 16 Complimentary BJT’s in Each Power Amp Section
• Transformer: Custom Toroidal Transformer
• EQ: Active, Serial, Variable Q, 4-band, Bump, Contour, Presence switches
• Inputs: 1 x 1/4″, 1 x 1/8 (aux)
• Outputs: 2 x SpeakON (1001RB), 6 x SpeakON (2001 RB), 1 x XLR (direct out), 1 x 1/4″ (tuner)
• Headphones: 1 x 1/8″ (Studio Quality)
• Effects Loop: Unbalanced ¼” Send and Return
• Footswitch (Included): 1 x 1/4″ (boost)
• Cooling System: 1 x Internal Fan with Thermal Speed Control (1001 RB) 2 x Internal Fans (2001 RB), Side and Back Intake Vents, Front Exhaust Vents
• Power Source: Standard IEC AC cable
• Chassis: Anodized Aluminum, Laser Etched Graphics
• Height: 5.25″
• Width: 17.2″
• Depth: 13″
• Weight: 41 lbs
